RainPoint 1″ AC Garden Solenoid Valves

Description

RainPoint 1″ AC Garden Solenoid Valves

The RainPoint solenoid valve is designed to efficiently control water flow in low-flow irrigation systems. It's ideal for gardens, greenhouses, and other small spaces that require precise irrigation management. With its 24V AC power supply and manual flow control, the valve combines reliability and convenience.

Effective operation under various conditions

The valve operates with a wide range of flow rates, from 0.05 to 9 m³/h, and pressures, from 0.5 to 8 bar, making it suitable for both simple and complex installations. Thanks to its ability to withstand liquid temperatures up to 60°C, it is perfectly suited to handle drinking water and diluted soluble fertilizers.

long-lasting

The fiberglass-reinforced nylon casing offers resistance to mechanical damage and atmospheric agents, while the EPDM (ethylene propylene diene monomer, a synthetic rubber with high resistance to atmospheric and chemical agents) rubber diaphragm ensures sealing and durability. The device is characterized by high resistance to chemical corrosion and cavitation, resulting in long-term, trouble-free operation.

Low energy consumption

The valve features very low current consumption: the starting current is 0.3 A and the holding current is 0.18 A, allowing multiple valves to be connected to a single controller. The power supply is 24 V ±101 VAC, 50/60 Hz, a standard in most irrigation control systems.

Ease of use

The valve features a manual switch and flow control knob for easy testing and setup without having to power up the entire system. Clear flow direction indications and compact dimensions (126 x 124 x 90 mm) make installation quick and easy.
